| Engine | |
|---|---|
| Horsepower (HP) | 50 HP |
| Engine Capacity (cc) | 3120 cc |
| Engine RPM | 2200 RPM |
| Cylinder | 3 |
| Air Filter | Dry type |
| Cooling Type | Forced Circulation of Coolant & Water |
| Transmission | |
|---|---|
| Clutch Type | (Optional) Dual & Single |
| Transmission Type | Constant Mesh |
|---|
| Forward Speed | 2.43 – 33.99 kmph |
|---|
| Reverse Speed | 3.04 – 11.96 kmph |
|---|
| Forward Gears | 8 |
|---|
| Reverse Gears | 2 |
|---|
| Brakes | |
|---|---|
| Brake Type | Oil Immersed Brakes |
| Turning Radius (Brake) | 2600 mm |
| Steering | |
|---|---|
| Steering Type | Power / Mechanical Steering |
| Steering Adjustment | NO |
| PTO Power | |
|---|---|
| PTO Type | 6 Spline |
| PTO RPM | 540 |
| PTO Power (HP) | 45 HP |
| Fuel Tank | |
|---|---|
| Fuel Tank Capacity (L) | 50 liters |
| Dimension & Weight | |
|---|---|
| Weight | 3210 kg |
| Wheelbase | 2200 mm |
| Overall Length | 3650 mm |
| Hydraulics | |
|---|---|
| Lift Capacity | 1800 kg |
| Tyre Size | |
|---|---|
| Front Tyres | 6 X 16 |
| Rear Tyres | 14.9 X 28 / 16.9 X 28 |
| Drive & Warranty | |
|---|---|
| Drive Type | 2WD |
| Warranty | NA |
