| Engine | |
|---|---|
| Horsepower (HP) | 27 HP |
| Engine Capacity (cc) | 1261 cc |
| Engine RPM | 2500 RPM |
| Cylinder | 3 |
| Air Filter | Dry type |
| Cooling Type | Liquid Cooled |
| Transmission | |
|---|---|
| Clutch Type | Dry single friction plate |
| Transmission Type | Constant Mesh |
|---|
| Forward Speed | 1.0 – 19.8 kmph |
|---|
| Reverse Speed | NA |
|---|
| Forward Gears | 9 |
|---|
| Reverse Gears | 3 |
|---|
| Brakes | |
|---|---|
| Brake Type | Oil Immersed |
| Turning Radius (Brake) | 2100 mm |
| Steering | |
|---|---|
| Steering Type | Power Steering |
| Steering Adjustment | NO |
| PTO Power | |
|---|---|
| PTO Type | 6 Spline |
| PTO RPM | 540, 750 |
| PTO Power (HP) | 19 HP |
| Fuel Tank | |
|---|---|
| Fuel Tank Capacity (L) | 23 liters |
| Dimension & Weight | |
|---|---|
| Weight | 650 kg |
| Wheelbase | 1560 mm |
| Overall Length | 2410 mm |
| Hydraulics | |
|---|---|
| Lift Capacity | 750 kg |
| Tyre Size | |
|---|---|
| Front Tyres | 7 X 12 |
| Rear Tyres | 8.3 X 20 |
| Drive & Warranty | |
|---|---|
| Drive Type | 4WD |
| Warranty | 5 year |
